Oversuspension kit for KTM 450 RALLY REPLICA Sanders Edition YEAR 2026

Oversuspension kit for KTM 450 RALLY REPLICA Sanders Edition YEAR 2026

Name: Oversuspension kit for KTM 450 RALLY REPLICA Sanders Edition YEAR 2026
Brand: Oversuspension
SKU: ROVS-T3#0005
Price: 479.15 USD
Availability: InStock

$479.15

More traction on acceleration

Brake later and harder

More control at high speeds

Reduce your fatigue and tension in the stage

Description

Greater Safety and Better Performance for Your Motorcycle:

More traction, better braking, reduced tire wear, and less fatigue while riding.

Kit includes: Support #0005, cylinder, clamp, screws, installation manual, and sealed box.

TECHNICAL SPECIFICATIONS

Light alloy body made of Ergal 7075 and 0.02 mm anodized
Internal sliding bearing composed of two half-shells of composite material reinforced with Kevlar and PTFE.
Percussion mass made of submicron grain sintered tungsten, mirror polished and ground at both ends.
Spring guide cap made of Kevlar and PTFE reinforced composite.
Spring made of chrome-silicon alloy subjected to two controlled shot peening cycles before and after heat treatment, with the head coils subjected to precision grinding.
Cap made of 6082 light alloy and anodized.
Spring preload assembly made of Kevlar reinforced composite.
Red knob made of Ergal 7075.
Bracelet made of 2024 Avional alloy and black anodized.
Coupling made of 6085 light alloy and obtained from a destressed plate.
Damper, based on polyurethane with powders of reserved composition.
All screws and nuts made of AISI 316 steel.
Velocite No. 3 ISO VG10 type lubricant with added PTFE.
NBR70 sealing O-ring.
Washable marine grease for knob lubrication.

TRY IT FOR 30 DAYS

😃 Only very satisfied customers.

We give you one month to try it out at your leisure, with no obligation.

And if you don't feel more poise, confidence, and flow in your driving, please return it 🙏

No questions asked, we'll arrange for it to be picked up at your home, quickly and at no cost to you.

LIFETIME WARRANTY AND AFTER-SALES SERVICE

Our highest production standards and the quality of our materials allow us to guarantee the device's lifetime operation (knocks and scratches are excluded).

Activate your warranty here.

Furthermore, if you change motorcycles, you only need to invest in the mount.

Oversuspension kit for KTM 450 RALLY REPLICA Sanders Edition YEAR 2026

$479.15

lifetime warranty

try it 30 days

free returns

payment in installments

"I installed it on my BMW R nineT and the riding feel is much smoother. The chassis feels more refined over uneven road surfaces."

"Where before I would feel a jolt when going over a bump, now it feels like a cushioned and controlled impact. The bike settles much faster after a jump or unevenness."

"I was able to test my Kove 800X Pro with the Oversuspension installed and I was surprised by the great improvement. On a rocky climb where my companion got stuck, I went up without traction problems as if I had a special system."

"Unbelievable! I was a bit skeptical installing it on my CBR1000RR-R, but I can really feel how much more the tire grips the road surface."

NEED HELP?

FREQUENTLY ASKED QUESTIONS

What is Oversuspension?

OVERSUSPENSION is the first and only device in the world that controls tire rebound, thus exponentially increasing riding safety and significantly improving your motorcycle's handling.

Why doesn't a motorcycle's suspension control tire rebound?

A motorcycle's shock absorber only manages the elasticity of the chassis with the rest of the rear end.

Oversuspension manages the elasticity of your tire with the swingarm.

We are talking about two separate elastic entities that work at different frequencies:

A standard shock absorber averages 1.2 cycles/second.
Oversuspension averages 18 cycles/second.

If I control the elasticity of the tire, I reduce the disorder in the system.

What benefits does Oversuspension generate?

With Oversuspension installed on your motorcycle, you will enjoy more traction, better braking, less riding fatigue, and less tire wear.

40% increase in traction

90% reduction in highside crashes

60% reduction in aquaplaning effect

30% reduction in musculoskeletal fatigue

How do you install the Oversuspension?

We recommend that the Oversuspension kit be installed by a specialized workshop.

If you access the following link, you can view the installation manual for the Oversuspension road bike kit:

https://oversuspension.es/pages/manual-instalacion-kit-oversuspension-moto-carretera

If your motorcycle is an off-road model, you can view the installation manual at the following link: https://oversuspension.es/pages/manual-de-instalacion-bmw-monobrazo

How does Oversuspension work?

Oversuspension is a high-tech mechanical component.

It consists of a mobile central core of heavy metal, a tungsten alloy that slides in a bushing with ballistic technology.

An aeronautical-grade spring pushes this mass against a special polymer that changes its structure depending on the force with which it is compressed.

The impact energy pushes the wheel against the ground, up to 35 times in a single second.

How does oversuspension affect a motorcycle's electronic suspension?

By integrating our vibrational technology with an electronic suspension system, the amount of information the ECU needs to manage is reduced, which optimizes its response and improves the overall efficiency of the suspension system.

In addition, our system also optimizes other electronically managed elements such as ABS, reducing its workload and allowing it to operate more precisely and efficiently.

How does oversuspension affect a Cardan shaft drive?

Un uncontrolled Tire Rebound generates vibrations that affect your motorcycle's transmissions and gears.

The use of Oversuspension in Cardan-type transmissions minimizes microgear wear, known as pitting. Avoid Costly Breakdowns.

How is the Oversuspension device regulated on a motorcycle?

The Oversuspension device can be adjusted depending on the use, type of terrain, and weather conditions.

The following adjustment scheme always refers to the device starting from fully open, towards the + sign.

ADJUSTMENT FOR 24-CLICK DEVICE

The adjustment for using the device in MOTOCROSS is as follows:

On a sandy track, the device should be kept fully open, i.e., towards the + position. In this way, the spring preload on the mass will be minimal and will adapt better to sandy tracks.
On muddy tracks, always keep the device fully open towards the + position.
On hard, dry tracks with shallow bumps, close the device 4 clicks towards the - position.
On hard, dry tracks with deep bumps, close the device 8 clicks towards the - position.
On Super Cross type tracks, close the device 6 clicks towards the - position.

The adjustment for using the device in ENDURO is as follows:

On timed tracks, close 2 clicks towards the - sign.
On slippery tracks and surfaces, leave everything open towards the + sign.
For Trial Cross: close 4 clicks towards the - sign.

The adjustment for using the device on a RACE TRACK is as follows:

In wet conditions (WET), the device should be left completely open towards the + sign.
On a dry track with undulations, close 4 clicks towards the - sign.
On a dry track with a smooth surface, adjust all settings to open towards the + sign.

The adjustment for using the device in
MAXI-TRAIL is as follows:

Road with rain: completely open towards the + sign.
Uneven trail: close 4 clicks towards the - sign.
With passenger: add 6 clicks to the previous settings.

The adjustment for using the device on the ROAD is as follows:

In rain, fully open to the + sign, even with a passenger.
On dry roads, close 2 clicks towards the - sign.
On dry roads, with a passenger, close 4 clicks towards the - sign.
On dry roads, with luggage and a passenger, close 8 clicks towards the - sign.

The adjustment for the RALLY version is as follows:

This refers only to the specific Rally kit version.
In the desert, close 2 clicks towards the - sign.
In the desert with rocks and many bumps, close 6 clicks towards the - sign.

ADJUSTMENT FOR 18-CLICK DEVICE

The adjustment for using the device in MOTOCROSS is as follows:

On a sandy track, the device should be kept fully open, i.e., towards the + position. In this way, the spring preload on the mass will be minimal and will adapt better to sandy tracks.
On muddy tracks, always keep the device fully open towards the + position.
On hard, dry tracks with shallow bumps, close the device 2 clicks towards the - position.
On hard, dry tracks with deep bumps, close the device 5 clicks towards the - position.
On Super Cross type tracks, close the device 4 clicks towards the - position.

The adjustment for using the device in ENDURO is as follows:

On timed tracks, close 1 click towards the - sign.
On slippery tracks and surfaces, leave everything open towards the + sign.
For Trial Cross: close 2 clicks towards the - sign.

The adjustment for using the device on a RACE TRACK is as follows:

In wet conditions (WET), the device should be left completely open towards the + sign.
On a dry track with undulations, close 2 clicks towards the - sign.
On a dry track with a smooth surface, adjust all settings to open towards the + sign.

The adjustment for using the device in
MAXI-TRAIL is as follows:

Road with rain: completely open towards the + sign.
Uneven trail: close 2 clicks towards the - sign.
With passenger: add 4 clicks to the previous settings.

The adjustment for using the device on the ROAD is as follows:

In rain, fully open to the + sign, even with a passenger.
On dry roads, close 1 click towards the - sign.
On dry roads, with a passenger, close 2 clicks towards the - sign.
On dry roads, with luggage and a passenger, close 5 clicks towards the - sign.

The adjustment for the RALLY version is as follows:

This refers only to the specific Rally kit version.
In the desert, close 1 click towards the - sign.
In the desert with rocks and many bumps, close 4 clicks towards the - sign.

ADJUSTMENT FOR 12-CLICK DEVICE

The adjustment for using the device in MOTOCROSS is as follows:

On a sandy track, the device should be kept fully open, i.e., towards the + position. In this way, the spring preload on the mass will be minimal and will adapt better to sandy tracks.
On muddy tracks, always keep the device fully open towards the + position.
On hard, dry tracks with shallow bumps, close the device 2 clicks towards the - position.
On hard, dry tracks with deep bumps, close the device 4 clicks towards the - position.
On Super Cross type tracks, close the device 3 clicks towards the - position.

The adjustment for using the device in ENDURO is as follows:

On timed tracks, close 1 click towards the - sign.
On slippery tracks and surfaces, leave everything open towards the + sign.
For Trial Cross: close 2 clicks towards the - sign.

The adjustment for using the device on a RACE TRACK is as follows:

In wet conditions (WET), the device should be left completely open towards the + sign.
On a dry track with undulations, close 2 clicks towards the - sign.
On a dry track with a smooth surface, adjust all settings to open towards the + sign.

The adjustment for using the device in
MAXI-TRAIL is as follows:

Road with rain: completely open towards the + sign.
Uneven trail: close 2 clicks towards the - sign.
With passenger: add 3 clicks to the previous settings.

The adjustment for using the device on the ROAD is as follows:

In rain, fully open to the + sign, even with a passenger.
On dry roads, close 1 click towards the - sign.
On dry roads, with a passenger, close 2 clicks towards the - sign.
On dry roads, with luggage and a passenger, close 4 clicks towards the - sign.

The adjustment for the RALLY version is as follows:

This refers only to the specific Rally kit version.
In the desert, close 1 click towards the - sign.
In the desert with rocks and many bumps, close 3 clicks towards the - sign.

Does the Oversuspension device require maintenance?

Being a mechanical device, without oils or greases, the Oversuspension device does not require maintenance.

You just have to pay attention to the usual cleaning of your motorcycle.

We periodically recommend checking the tightening torques of the
fastening screws.

Is the Oversuspension device a tuned mass damper?

Unlike the mass damper, which has a mass and two springs embracing it, the Oversuspension device is a mass that strikes a special polymer.

Does the product have a lifetime warranty?

The Oversuspension device is guaranteed for life.

The high quality of our materials and the precision of our manufacturing processes allow us to offer this guarantee.

The warranty does not cover scratches, dents, or other cosmetic damage caused by use.

What is the delivery time for an order?

You will receive your order at the address provided within a maximum of 15-20 business days.

Which countries is the Oversuspension device shipped to?

We ship to all these countries:

Spain, Portugal, Andorra, Bulgaria, Croatia, Cyprus, Czechia, Denmark, Estonia, Finland, Germany, Greece, Hungary, Ireland, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Romania, Slovakia, Slovenia, Sweden, Italy, Mexico, United States, France, Austria, Belgium, Australia, New Zealand, Anguilla, Malaysia, Norway, Switzerland, Canada, United Kingdom, Antigua and Barbuda, Argentina, Aruba, Bahamas, Barbados, Belize, Bermuda, Bolivia, Brazil, British Virgin Islands, Caribbean Netherlands, Cayman Islands, Chile, Colombia, Cook Islands, Costa Rica, Curaçao, Dominica, Dominican Republic, Ecuador, El Salvador, Falkland Islands, Fiji, French Guiana, Grenada, Guatemala, Guyana, Haiti, Honduras, Jamaica, Kiribati, Martinique, Montserrat, Nauru, Nicaragua, Niue, Norfolk Island, Panama, Paraguay, Peru, Pitcairn Islands, Sint Maarten, Solomon Islands, Saint Barthélemy, Saint Kitts and Nevis, Saint Lucia, Saint Martin, Saint Pierre and Miquelon, Saint Vincent and the Grenadines, Suriname, Timor-Leste, Tokelau, Trinidad and Tobago, Turks and Caicos Islands, Tuvalu, US Minor Outlying Islands, Uruguay, Venezuela, Wallis and Futuna

Can I return the product if I'm not satisfied?

If you are not satisfied with the performance of the Oversuspension kit, you have a 30-calendar-day return period from the date you receive your order. Return shipping is free.
